Galley Equipment :
DL SERVICES : As independent designers, we cater to our customers wishes, actively participating in new building and modernization / refit projects, putting together food flow concepts, lay-out designs with itemized budgeted equipment specifications, turnkey specifications and installation...
MKN
Professional cooking technology in perfection
DETAILS
MKN, German professional cooking technology specialist
Enjoy Cooking with MKN!
MKN (Maschinenfabrik Kurt Neubauer) is a German specialist for the development, manufacture and worldwide sales of premium professional thermal cooking technology. MKN looks back on 70 years of special expertise which has given rise to a comprehensive product range covering all thermal processes applied in professional kitchens as well as being geared towards user-friendly optimization of kitchen workflows. In recent years exportable equipment innovations have resulted in a strong level of internationalization. With around 500 employees and worldwide business, MKN is now one of the industry’s global players.
The FlexiChef is a powerful all-rounder at a high level of professional cooking technology. Frying or cooking or pressure cooking or deep-frying, all with one appliance and on a small footprint. That’s productivity that pays off. Using FlexiChef is immediately intuitive and turbo-quick. And with SpaceClean, the first automatic cleaning system for pans, the appliance has a high-performance hygiene concept that cares for the environment and its resources.
Modern technology combined with extraordinary practicability, that is the MKN combi steamer FlexiCombi. Cooking with the multifunctional, flexible FlexiCombi is user-friendly, environmentally friendly, economical and reliable. Operated intuitively similar to a smartphone, the MKN FlexiCombi offers a wide range of applications. The intelligent, technical features guarantee top cooking results, capacity benefits and outstanding energy and water consumption levels. The consumption display GreenInside provides transparency here.
Many professional chefs appreciate the multifunctionality and user friendliness of a modern combi steamer but don’t have sufficient room in their kitchen or they need their combi steamers situated suitably for front cooking and at serving stations, where every centimetre counts. With the space saving SpaceCombi models, MKN offers a professional solution which is specially geared to these conditions. The SpaceCombi is only 55 cm wide, yet still comparably equipped to larger models. In addition, despite its slim width, it offers astounding capacity: 6 x 1/1GN in SpaceCombi Compact and 6 x 2/3 GN in SpaceCombi Junior.
Download
About MKN
Products
Combi oven MKN
Combi oven MKN
Combi oven MKN
6.1
Capacity: 6 GN1/1
Type: Electric
Functionality: Manual or Automatic cooking operation
Combi oven MKN
6.2
Capacity: 6 GN2/1
Type: Electric
Functionality: Manual or Automatic cooking operation
Combi oven MKN
10.1
Capacity : 10 GN1/1
Type: Electric
Functionality: Manual or Automatic cooking operation
Combi oven MKN
Combi oven MKN
20.1
Capacity: 20 GN1/1
Type: Electric
Functionality: Manual or Automatic cooking operation
Combi oven MKN
20.2
Capacity: 20 GN2/1
Type : Electric
Functionality: Manual or Automatic cooking operation
Grill grooved MKN
SIZE I SUPRA
Capacity: Griddle plate 440x500mm
Style: Floor model
CH2T: Exhaust ventilation required
CH2C: heat emission : sensitive 2376w Latent 2880w
CH3T: Electric connect.
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 7,2 Kw.
Measures: 600x850x850
Option1: .Splash guard, ref. 945010 .Fat discharge plug, ref. 970046 .Griddle plate scraper with brush (not for hard-chrome-plated execution), ref. 581050 .Half ribbed/half flat, ref. 2021108 .Flat, hard-chromed-plated, ref. 2021107A .Fully ribbed execution .Stainless steel execution .Electronic control
Grill grooved MKN
SIZE II SUPRA
Capacity: Griddle plate 700x500mm
Style: Floor model
CH2T: Exhaust ventilation required
CH2C: heat emission : sensitive 3564w Latent 4320w
CH3T: Electric connect.
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 10,8 Kw.
Measures: 800x850x850
Option1: .Splash guard, ref. 945015 .Fat discharge plug, ref. 970046 .Griddle plate scraper with brush (not for hard-chrome-plated execution), ref. 581050 .Half ribbed/half flat, ref. 2021110 .Flat, hard-chromed-plated, ref. 2021109A .Fully ribbed execution .Stainless steel execution .Electronic control
Deep fat fryer MKN
Deep fat fryer MKN
PARIS
Capacity: 1 pan, min. 15 L to max. 30 L
Style: Floor model
CH2T: Exhaust ventilation required
CH2C: heat emission : sensitive 900w Latent 7000w
CH3T: Electrical connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric Power
CH4C: 10 Kw.
Measures: 600x850x850
Included: .1 lid .1 fat clarifying tray .1 basket P .2 baskets L .1 drain cook key
Option1: .Fat receptable 30L, ref. 813006 .Basket lift with timer .Higher loading 20kw .Electronic control .Fat melting cycle .Set of 4 stainless steel legs h=150mm
Deep fat fryer MKN
LONDON II
Capacity: 2 pans, each min. 6,5 L to max. 12,5 L
Style: Floor model
CH2T: Exhaust ventilation required
CH2C: heat emission : sensitive 1080w Latent 8400w
CH3T: Electrical connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric Power
CH4C: 12 Kw.
Measures: 600x850x850
Included: .2 lids .2 fat clarifying trays .2 baskets L .1 drain cook keykey
Option1: .Fat receptable 30L, ref. 813006 .Basket lift with timer .Higher loading 20kw .Electronic control .Fat melting cycle .Set of 4 stainless steel legs h=150mm
FlexiCombi MagicPilot MKN
Kettle MKN
OPTIMA 2023003B
Capacity: 40/60 Liters
Style: manual tilting - lateral frame model
CH3T: Electric connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 16 kw.
Measures: 1100x850x850
Included: Drain cock strainer
Option1: .Mixing faucet R 3/4
Kettle MKN
OPTIMA 2023007B
Capacity: 80/100 Liters
Style: manual tilting - lateral frame model
CH3T: Electric connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 21 kw.
Measures: 1200x850x850
Included: Drain cock strainer
Option1: .Mixing faucet R 3/4
Kettle MKN
OPTIMA 2023009B
Capacity: 150 Liters
Style: manual tilting - lateral frame model
CH3T: Electric connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 26 kw.
Measures: 1300x850x850
Included: Drain cock strainer
Option1: .Mixing faucet R 3/4
Multifunctional Cooking equipment MKN
Pasta cooker MKN
AL DENTE
Capacity: 1 pan, max. 30 Liters
Style: Pan 400x400x245mm
CH2T: Exhaust ventilation required
CH2C: heat emission : sensitive 350w Latent 2000w
CH3T: Electric connect.
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 10 Kw.
Measures: 600x850x850
Included: One (1) perforated bottom grate
Technical: .Hot water: R1/2
Option1: .One (1) basket size I (1/4), ref. 206011 .One (1) basket size II (1/1), ref. 206012 .Continuous flow-water heater
Salamander MKN
SIZE I
Capacity: 2 heating zones, GN 1/1 pan
Style: Wall model
CH2T: Exhaust ventilation required
CH2C: .heat emission : sensitive 2310w Latent 578w
CH3T: Electric connect.
CH3C: 230v 1ph 50/60hz
CH4T: Electric power
CH4C: 3,3 Kw.
Included: One (1) removable grill grid with handles
Option1: .One (1) drip pan 1/1 GN, 20mm deep, ref. 202019 .One (1) heavy grill plate, ref. 521291 .One (1) wall bracket 630x395x315mm, ref. 581040
Tilting braising pan MKN
OPTIMA 20214 01
Capacity: GN2/1 - 59 L capacity, 44 L nominal capacity
Style: manual tilting - compact model
CH3T: Electric connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 10,8 kw.
Measures: 800x850x850
Technical: .Drain Connection: Gutterway .Exhaust ventilation required: heat emission: sensitive 4860w Latent 4320w
Option1: .Electronic control
Tilting braising pan MKN
OPTIMA 20214 03
Capacity: GN2/1 - 59 L capacity, 44 L nominal capacity
Style: manual tilting - lateral frame model
CH3T: Electric connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 10,8 kw
Measures: 1300x850x850
Technical: .Hot water connection: R1/2
Option1: .Electronic control
Tilting braising pan MKN
OPTIMA 20214 05
Capacity: GN3/1 - 85 L capacity, 63 L nominal capacity
Style: manual tilting - lateral frame model
CH3T: Electric connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric power kw
CH4C: 14,4
Measures: 1600x850x850
Technical: .Hot water connection: R1/2
Option1: .Electronic control
Tilting pressure braising pan MKN
OPTIMA EXPRESS 2024203
Capacity: GN3/1
Style: manual tilting
CH3T: Electric connection
CH3C: 400v 3ph 50/60hz
CH4T: Electric power
CH4C: 19,4 kw.
Measures: 1600x850x850
Option1: .Stainless steel legs h=150mm .Mixing battery R 3/4
Tilting pressure braising pan MKN
OPTIMA EXPRESS 2024201
Capacity: GN2/1
Style: manual tilting
CH3T: Electric connection
CH3C: 400v / 3ph / 50-60hz
CH4T: Electric power
CH4C: 14,6 kw.
Measures: 1300x850x850
Option1: .Stainless steel legs h=150mm .Mixing battery R 3/4
Gallery
Pictures
Products
Videos
MKN FlexiChef®
References
Owner : BRITTANY FERRIES
Ferries
New building |
Owner : AIDA CRUISES
Cruise Ships
Modernization |
Owner : CELEBRITY CRUISES
Cruise Ships
New building |
Owner : CARNIVAL CRUISE LINE
Cruise Ships
New building |
Owner : COSTA CRUISES
Vessel : COSTA LUMINOSA, COSTA DELIZIOSA
Cruise Ships
New building |
Owner : CRYSTAL CRUISES
Cruise Ships
New building |
Owner : CUNARD LINE
Vessel : QUEEN MARY II
Cruise Ships
New building |
Owner : MSC CRUISES
Cruise Ships
New building |
Owner : NORWEGIAN CRUISE LINE
Vessel : NORWEGIAN BREAKAWAY
Cruise Ships
New building |
Owner : OCEANIA CRUISES
Cruise Ships
New building |
Owner : P&O FERRIES
Ferries
New building |
Owner : PRINCESS CRUISES
Cruise Ships
New building |
Owner : PULLMANTUR CRUISES
Cruise Ships
New building |
Owner : REGENT SEVEN SEAS CRUISES
Cruise Ships
New building |
Owner : ROYAL CARIBBEAN CRUISES LINES
Vessel : ALLURE OF THE SEAS
Cruise Ships
New building |
Owner : SEABOURN CRUISE LINE
Cruise Ships
New building |
Owner : SILVERSEA CRUISES
Cruise Ships
New building |
Owner : STAR CLIPPERS
Cruise Ships
New building |
Owner : DEILMANN
Vessel : MS DEUTSCHLAND
Cruise Ships
New building |
News
NEW MKN COMBI STEAMER TRIUMPHS AT RENOWNED AWARDS
29th of February 2016
MKN is thrilled as its new combi steamer FlexiCombi Team celebrates double success after winning two international innovation awards. The Gulfood Awards were presented on the occasion of the same named exhibition in Dubai and rank among the most renowned accolades in the industry. The Gulfood Awards honour and recognise individuals as well as companies for particularly outstanding and innovative products. Three hundred...
Enjoy Space! With the new MKN SpaceCombi
27th of February 2017
SpaceCombi - So much packed into a little space Many professional chefs appreciate the multifunctionality and user friendliness of a modern combi steamer. However, some of them don’t have sufficient room in their kitchen or they need their combi steamers situated suitably for front cooking and at serving stations, where every centimetre counts. With the space saving SpaceCombi models, MKN offers a professional solution...
Contact us
Contact Details
MKN
Maschinenfabrik Kurt Neubauer GmbH & Co. KG - Halberstaedter Strasse 2a - 38300 Wolfenbuettel - Germany
Tél: +49 5331 89-207
Fax: +49 5331 89-418
http://www.mkn.eu
